| Model: ATF | F02-51.2100 | F02-51.2200 | F02-51.2314 |
| Nominal Voltage (V) | 51.2 | ||
| Cell Specification (Ah) | 100 | 200 | 314 |
| Nominal Capacity (Ah) | 100 | 200 | 314 |
| Nominal Energy (kWh) | 5.12 | 10.24 | 16.07 |
| Operating Voltage Range (V) | 44.8-58.4 | ||
| Recommended Charging Voltage (V) | 56.8 | ||
| Recommended Discharge Cut-off Voltage (V) | 44.8 | ||
| Maximum Charging Current (A) | 50 | 100 | 150 |
| Maximum Discharging Current (A) | 50 | 100 | 150 |
| Cycle Life | 6000 cycles (0.5C, 90% DOD, 25°C) | ||
| Chassis Dimensions (W*D*H) mm | 440*550*140 | 560*780*140 | 440*780*235 |
| Weight (kg) | 43 | 80 | 133 |
| Communication Method | CAN/RS485/Bluetooth/WiFi | ||
| Number of Parallel Units | 20 units | ||
| Permissible Humidity Range (%RH) | 15~85 | ||
| Storage Ambient Temperature (°C) | -20~60 (Recommended 10~35) | ||
| Charging Ambient Temperature (°C) | 0~50 (Recommended 10~35) | ||
| Discharging Ambient Temperature (°C) | -10~60 (Recommended 10~35) | ||
| Altitude (m) | ＜3000 | ||
| Protection Level | IP20 | ||
| Cooling Method | Natural air cooling | ||
| Operating Conditions | Indoor | ||
| Protection method | Overvoltage, undervoltage, pressure differential, overtemperature, capacity, short circuit, communication failure, etc. | ||
| Certificate | UN38.3, MSDS, CE | ||
| Note: The above data are for reference. In case of any changes, no further notice will be given. For special customization requirements, please contact the equipment manufacturer. | |||
